Uncompressed 4K DVI to Fiber Converter | DVI Fiber Optic Extender

4K HD DVI optical transceiver supports 4K resolution and 10G high-speed photoelectric conversion transmission. It is actually a single fiber to extend the DVI signal, speaker, microphone, RS232, etc. EDID real-time backhaul, support to transmit RS232 serial port signal, used for communication with LCD screen, camera gimbal, and can also be used as long-distance transmission of touch screen. Low energy consumption, long distance, plug and play, strong compatibility, can achieve more accurate display.

● All digital, no compression, high-definition fiber transmission;

● 10G optical fiber transmission rate, truly transparent transmission without compression and delay;

● Support DVI-D video signal transmission, the highest resolution: 4096 × 2160 @ 30HZ;

● EDID can be reversed to support HDCP content protection;

● Automatically identify and configure various display modes;

● With independent analog audio or RS232 / 422/485 serial data;

● DVI interface has built-in ESD protection circuit, which can effectively prevent static electricity loss;

● On-site installation: simple and convenient, plug and play, no setting required;

● 300 meters of multimode fiber, 10 ~ 80KM long distance transmission of single mode fiber;

● The aluminum alloy oxygen pole oxidation shell is suitable for severe industrial environments such as extremely high temperature and extremely low temperature;

● Full surface mount technology and high reliability;

● No software setting required, support plug and play function, support hot swap.

● Fiber

Fiber: single fiber, double fiber

Fiber interface: LC

Wavelength: 850nm / 1310nm multimode; 1310nm / 1550nm single mode

Transmission distance: 10 ~ 80Km

Typical transmit power:

Single mode 1310 / 1550nm: ≥-9dBm

Multimode 850nm: -18dBm

Multimode 1310nm: -25dBm

Receiving sensitivity range: -33dBm ~-40dBm

● DVI Port

● Power

System power: AC180V ～260V; DC –48V; DC +24V

Power consumption: ≤10W

● Working Environment

Working temperature: -10℃—+60℃

Storage temperature: -40℃—+85℃

Working Humidity: 0%—95%（no condensation）

MTBF: ＞100,000 hour
