Managed Din-Rail 4-Port 10/100/1000Base-T 802.3af/at POE + 2-Port 1000M SFP Industrial Switch (Dual DC supports POE+)

View : 237
Type : Managed Din Rail Industrial Switch
Description :

The industrial-grade ethernet switch with 4*10/100/1000Base-T+2*1000Base-FX and network management capabilities is a smart industrial network switch product specifically designed for the security and surveillance industry.


The industrial-grade ethernet switch with 4*10/100/1000Base-T+2*1000Base-FX and network management capabilities is a smart industrial network switch product specifically designed for the security and surveillance industry. It supports the STP/RSTP protocol of the international standard IEEE 802.3D/W/S, as well as rich network management functions, providing stable and reliable ethernet transmission with high-quality design and reliability. It can provide users with efficient bandwidth, reliable fiber optic network solutions for Ethernet data exchange, aggregation, and remote optical transmission.


It is suitable for low-temperature and high-temperature environments, is resistant to strong electromagnetic interference, salt spray, and shock, and is equipped with redundant dual DC power supplies (9-70V) to provide a redundant mechanism for critical devices that require a continuous connection. It supports DIN rail or wall-mounted mounting and has an IP40 protection level, making it a perfect choice for harsh environments.


With an IP40 protection level and an aluminum alloy anodized shell, the device can withstand harsh environments.

The device provides 4 Gigabit Ethernet ports and 2 Gigabit optical ports with a transmission bandwidth of line-speed 1000M. The Gigabit optical ports support distance transmission of 20/40/60/80/120KM.

The cache reaches 1Mbit, which can meet the smooth transmission of 4K video. It supports the transmission of IEEE802.1Q protocol VLAN’s extra-long data packets, supports Ethernet packets up to 16K bytes, and supports large backplane bandwidth and exchange cache, ensuring that all ports forward at line speed.

The ethernet port (RJ45) supports 10/100/1000M adaptive, full/half-duplex mode, and MDI/MDI-X automatic detection.

When powered by DC power (>DC48V), it can support POE (POE+) with a power output of 802.3af/at (15.5w/25.5w) per port (optional).

It supports the STP/RSTP ring network protocol of the IEEE 802.3D/W/S, and one-click can form an RSTP ring network.

It supports IEEE802.3/802.3u/802.3ab/802.3z/802.3x store-and-forward mode.

It supports IGMP Snooping V1/V2/V3, GMRP, IEEE 802.1Q 4K VLAN, and DSCP 8 queues.

It has a powerful lightning protection function for the power supply: anti-lightning strike, high-voltage induction resistance, surge protection, etc. It has a fanless design for efficient heat dissipation, reducing repair time.

● When powered by dual DC (5.08mm wiring terminal):

  ♦ It can be powered by a wide range of DC9-70V or AC7-50V power supplies, and the power supply has automatic polarity detection function, no need to distinguish between positive and negative poles during installation.

  ♦ It supports internal isolation, redundant dual power input, and reverse connection protection.

● When powered by AC (three-pin AC socket):

  ♦ It supports AC~85-265V AC or DC110-300V DC wide-range input, which meets the requirements of industrial-grade electromagnetic compatibility.

DIN 35mm rail mounting or wall-mounted.

Working temperature: -40℃~ +85℃.

The switch has passed 100% burn-in testing, and the warranty period is 5 years.


● Fiber Port

Optical port: 2

Optical Fiber: Single/Dual fiber

Fiber interface: SC/FC/ST/LC(SFP) optional

Wavelength: 850nm/1310nm multi-mode; 1310nm/1550nm single-mode

Relay-free transmission distance: 0~80Km

Typical transmission power: single mode 100uw — 0.93m


● 10/100/1000M Ethernet Port

Protocol: Conforms to IEEE 802.3ab, IEEE 802.3z

Rate: 10/100/1000M adaptive, full/half duplex adaptive

MAC Address Capacity: can learn 4096 MAC addresses

Physical Interface: RJ45 seat, support Auto-MDIX


Ethernet POE Features

PoE standard: IEEE 802.3af/at

PoE type: end-span (also supports mid-span)

PoE port features: port output power 25.5W

POE power supply wire core: end jumper method 1/2+, 3/6-line pair (middle jumper method 4/5+, 7/8-line pair)


● Working Environment

Working temperature: -40 ° C – +85 ° C

Storage temperature: -40 ° C – +85 ° C

Working humidity: 0% – 95% (no condensation)

MTBF: >100,000 hours


Product Model


Function Description

2*gigabit optical ports to 4*10/100/1000M ethernet ports, industrial rail type

Port Description

2*gigabit SFP optical ports, 4*gigabit Ethernet ports

Power Supply

DC power supply:

Redundant dual power input DC9-70V or AC7-50V, power consumption <5W

Overload protection: support; reverse polarity protection: support; redundant protection: support

Access terminal: 4-core 5.08mm pitch plug-in terminal

AC built-in power supply:

AC~85-265V AC, or DC110-300V DC wide range input, power consumption <5W

Overload protection: support;

Access interface: 3-pin AC socket

Product Size

Shell: IP40 protection grade, aluminum alloy material

Dimensions: 110mm(L) x 87mm(W) x 40mm(H)

Mounting method: DIN rail, wall-mounted





Application of switch
