2-Port Ethernet to E1 Converter

View : 1,267
Type : Single E1-Ethernet Bridge
Description :

This device is based on FPGA. It multiplexes 2 10/100base-T Ethernet interfaces to an E1 interface, providing users with 2 Ethernet accesses with a maximum rate of no more than 1984K.

Overview

This device uses large-scale FPGA design to multiplex 2 10/100base-T Ethernet interfaces into the E1 interface, providing users with access to 2 Ethernet interfaces with a maximum speed of no more than 1984K. It is widely used in the financial, securities, and security departments that require two different networks that can be physically isolated from each other.


framed 2 ports ethernet to e1 converterframed 2 ports ethernet to e1 converter

Features

It can realize 2-channel Ethernet data transmission over the E1 circuit;

It has a built-in dynamic Ethernet MAC address list (4096 entries) with a local data frame filtering function;

The total Ethernet rate is 1984Kbps for both channels, and the second Ethernet channel is automatically allocated after the first one is configured;

It can force the remote device to follow the local device’s rate setting;

The device can detect E1 loopback and indicate it with LED lights, and prevent the Ethernet port from sending packets with the same source and destination MAC addresses during loopback to avoid switch crashes;

It can distinguish between remote power failure and E1 line break when E1 signal is lost;

● The Ethernet interface supports jumbo frames (2036 Bytes);

● Ethernet interface supports 10/100M, half/full duplex auto-Negotiation, and AUTO-MDIX  (auto-negotiation of crossover and straight-through connections);

The device has an automatic reset function for Ethernet data monitoring to prevent crashes.

It provides two clock modes: E1 master clock and E1 line slave clock;

The device provides 3 loopback modes: E1 local loopback (ANA), Ethernet local loopback (DIG), and Remote Ethernet loopback (REM);

It supports both 120Ω/balanced and 75Ω/unbalanced impedance, without the need for additional configuration;

● Support SNMP Network Management.

Parameters

● E1 Interface

Interface Standard: Comply with protocol G.703;

Rate: n*64Kbps±50ppm;

Line Code: HDB3;

E1 Impedance: 75Ω (unbalance), 120Ω (balance);

Jitter Performance: Compliant with G.742 and G.823

Input Port Attenuation Allowed: 0~6dBm



● Ethernet Interface (10/100M)

Interface rate: 10/100 Mbps, half/full duplex auto-negotiation

Interface Standard: Compatible with IEEE 802.3, IEEE 802.1Q (VLAN)

MAC Address Table: 4096

Connector: RJ45, support Auto-MDIX



● Working Environment

Working temperature: -10°C ~ 50°C

Working Humidity: 5%~95 % (no condensation)

Storage temperature: -40°C ~ 80°C

Storage Humidity: 5%~95 % (no condensation)

Specifications

Model

FCC-E1fF2p

Function Description

2FE transmission over 1channel framed E1, ethernet support Physical isolation

Port Description1

 1*E1 interface, 2*FE Interface

Power Supply

Power supply: AC180V ~ 260V; DC –48V; DC +24V

Power consumption: ≤10W

Dimension

Product Size:  216X140X31mm (WXDXH),1.3KG/piece

Application

application of framed 2 channels ethernet to e1 converter
