30 Channel Voice over Ethernet (IP) Converter

The converter encapsulates the voice data in the IP packet, supports the UDP packet mode, and realizes the 1-30 voice service to the 100M Ethernet conversion, in the same network segment or through the router to achieve different network segment communication.

● High transmit efficiency, low transmit delay;

● Provide Console(CLI)/WEB management interface, easy to install and open;

●Voice port to support FXO/FXS/2-4 Wire E&M/2-4 wire Audio/Magnet phone interface, FXO port plug into PBX, FXS port is connected to the user’s telephone;

● Voice FXO/FXS interface, support for caller ID/reverse polarity billing/fax function;

● Both sides of the device support FXO+FXS hybrid access;

● Ethernet interface rate of 10/100M, full duplex/half duplex adaptive;

● Support power failure or automatic network recovery;

● Support Ethernet packet out-of-order recovery and cache to anti-network delay;

● Adjustable frame length to balance bandwidth and transmission delay;

● DC-48V/DC24V power supply with polarity automatic detection function; installation does not need to distinguish between positive and negative.

● 10/100M Ethernet Interface

Protocol: IEEE 802.3az, IEEE 802.1Q (VLAN)
Rate: 10/100M adaptive, full/half duplex fully adaptive
MAC address table: 4096 MAC addresses can be learned
Physical interface: RJ45 seat supports auto mdix

● FXS Phone Interface

Ring voltage: 75V
 Ring frequency: 25HZ
2-line Impedance: 600 Ohm (pick up)
Return loss: 40 dB

● FXO Switch Interface

Ring detect voltage: 35V
Ring detection frequency: 17HZ-60HZ
2-line Impedance: 600 Ohm (pick up)
Return loss: 40 dB

● EM 2/4 Line

AD: 0dB
DA: 0dB
Two/Four-line Impedance: 600 Ohm
Return loss: 20 dB

● Environmental Indicators

Operating temperature: – 10 ℃ – + 60 ℃
Storage temperature: – 40 ℃ – + 85 ℃
Working humidity: 0% – 95% (no condensation)
MTBF: ＞ 100000 hours
