60 Channel Analog Phone over Fiber Multiplexer
This device provides 60 channel FXO/FXS telephone, it supports 6U rack plug-in, and 6U rack can equipment with SNMP network management.
Overview
Features
● Support FXO/FXS, EM2/4 audio, Magnet Telephone Interface, FXO port is connected to a PBX, while FXS port is connected to a user’s telephone set;
● Voice FXO/FXS ports support Caller ID display, reverse polarity billing, and fax function;
● It supports mutual dialing between two sites;
● The transmission distance is up to 2-120Km without interruption;
● The 6U rack plug-in can be offered and support the SNMP ;
● The telephone interface is equipped with lightning protection that complies with IEC61000-4-5 standards for short circuit current wave 8/20μs and can withstand peak output voltages of up to 6KV;
● Multiple power supply can be optional: AC 220V, DC-48V, DC24V, etc.
Parameters
● Fiber
Multi-mode Fiber
50/125um, 62.5/125um,
Maximum transmission distance: 5Km @ 62.5/125um single mode fiber, attenuation (3dbm/km)
Wave Length: 820nm
Transmitting power: -12dBm (Min) ~-9dBm (Max)
Receiver sensitivity: -28dBm (Min)
Link budget: 16dBm
Single-mode Fiber
8/125um, 9/125um
Maximum transmission distance: 40Km
Transmission distance: 40Km @ 9/125um single mode fiber, attenuation (0.35dbm/km)
Wave Length: 1310nm
Transmitting power: -9dBm (Min) ~-8dBm (Max)
Receiver sensitivity: -27dBm (Min)
Link budget: 18dBm
● FXS Phone Port
Ring voltage: 75V
Ring frequency: 25HZ
2-Wire Impedance: 600 Ohm (pick up)
Return loss: 40 dB
● FXO Trunk Port
Ring detect voltage: 35V
Ring detection frequency: 17Hz-60Hz
2-Wire Impedance: 600 Ohm (pick up)
Return loss: 40 dB
● EM 2/4-Wire
AD: 0dB
DA: -3.5dB
2/4-Wire Impedance: 600 Ohm
Return Loss: 20 dB
● Working Environment
Working temperature: -10°C ~ 50°C
Working Humidity: 5%~95 % (no condensation)
Storage temperature: -40°C ~ 80°C
Storage Humidity: 5%~95 % (no condensation)
Specifications
| Product Model | FCP-O60/FCP-S60 |
| Function Description | Managed 60 POTS (FXO/FXS) over fiber |
| Power |
Power supply: AC180V ~ 260V; DC –48V; DC +24V Power consumption: ≤10W |
| Dimension | 19inch 485 X 200 X 45mm (WxDxH) |
| Weight | 2.4KG |
Application

Documentation and project verification — FCP-O60/FCP-S60
Before ordering or wiring, confirm the exact model and configuration, interface pinout, optical or network compatibility, power input and installation conditions. Optional configurations are not interchangeable.
