1080P@60Hz HDMI & USB KVM over Cat5/5e Ethernet Extender (120m)

The device is capable of converting HDMI signals into the IEEE802.3 network protocol, allowing for direct long-distance transmission up to 120 meters using Category 5 Ethernet cables or integration into a local area network. It supports a resolution of 1080P @60Hz. Not only does it overcome the limitations of HDMI cable length, but it also offers greater convenience, flexibility, and cost savings for a wide range of customers. It provides solutions for various applications such as environments with limitations on noise, transmission distance, and security, as well as data center control, information distribution, conference room presentations, educational settings, and corporate training venues.

● The device complies with HDMI1.3a standard and HDCP1.1 protocol.

● The transmitter has an HDMI loop-out interface.

● The transmitter has 1 USB port, and the receiver has 2 USB ports, allowing for keyboard and mouse connectivity.

● It automatically recognizes and configures various display modes.

● It supports resolutions up to 1080P@60Hz, with backward compatibility.

● It can be directly transmitted over a network cable, or over a Gigabit switch, and can be used in multiple pairs through switching. At this time, VLANs need to be set, and different pairs of devices should be divided into different VLANs.

● Built-in ESD protection circuit effectively prevents static electricity damage.

● Simple and convenient on-site installation, plug-and-play without the need for configuration.

● It has ultra-low video latency.

● No driver, compatible with any system, plug-and-play.

● The device is powered by 9-12VDC and can be connected to various power sources such as AC220V, DC-48V/DC24V, etc.

● 10/100/1000M Ethernet Interface

Protocol: Compliant with IEEE 802.3ab, IEEE 802.3z

Rate: 10/100/1000M adaptive, full/half duplex adaptive

Physical interface: RJ45 supports Auto-MDIX

● USB Interface

Standard: USB 1.1×1

Interface Type: USB 2.0 Type A Female

● Environmental Index

Working temperature: 0℃—+40℃

Storage temperature: -20℃—+60℃

Working humidity: 0%—95% (non-condensing)

MTBF: >100,000 hours

● HDMI Interface

Over Ethernet Application

Over Ethernet Switch Application
