16-Port 12G-SDI to Fiber Converter

View : 404
Type : HD-SDI to Fiber Converter
Description :

The 12G HD-SDI to fiber converter employs digital encoding technology to achieve long-distance bidirectional transmission of 16 channels of 12Gbps HD-SDI video signals through a single-mode optical fiber.

Overview

The 12G HD-SDI to fiber converter employs digital encoding technology to achieve long-distance bidirectional transmission of 16 channels of 12Gbps HD-SDI video signals through a single-mode optical fiber. The maximum distortion-free and non-relay transmission distance is 80 kilometers. The signal format of the device complies with SMPTE ST 2082-1 (12G UHD-SDI), ST 2081-1 (6G UHD-SDI), SMPTE 424M, SMPTE 292M, SMPTE 259M, SMPTE 297M, SMPTE 305M, and SMPTB3 10M standards.

Features

The device is fully aluminum alloy anodized and designed in a 19-inch 1U rack-mounted style.

The device is intended for paired use, with video signal input at one end and video signal output at the other end.

Various types are available, including ordinary desktop and centralized card-insertion rack.

It supports 12G-SDI/6G-SDI/3G-SDI/HD-SDI/SDI/ASI.

The maximum transmission distance is up to 80 kilometers.

Both the transmitter and receiver are equipped with LED indicators showing the status of SDI signal input.

The video interface provides three-level lightning protection, capable of passing the ITU-T K.21 (10/700 μS) test with a common mode of 6KV and impedance (40 Ω).

It is powered by AC220, and also compatible with DC-48V/+24V power supply.

Parameters

● Fiber Optic

Optical Ports: 1

Fiber Type: Single-mode

Fiber Interface: FC

Wavelength: 1310nm-1610nm Single-mode

Non-Relay Transmission Distance: 0~80Km

Typical Transmit Power: Single-mode 100uW — 0.93mW



● 12Gbps HD-SDI Video

Reflection Loss: >10dB (11.88 Gbps)

Automatic Cable Equalization:

>30m (11.88 Gbps) (Belden1694A cable)

>50m (5940 Mbps) (Belden1694A cable)

>100m (2970 Mbps) (Belden1694A cable)

>200m (1485 Mbps) (Belden1694A cable)

>350m (270 Mbps) (Belden1694A cable)

Video Characteristics:

12G-SD Rise/Fall Time: <40ps (11.88 Gbps)

6G-SD Rise/Fall Time: <66ps (5940 Mbps)

3G-SD Rise/Fall Time: <135ps (2970 Mbps)

HD-SD Rise/Fall Time: <270ps (1485 Mbps)

SDI Rise/Fall Time: <0.6ns (270 Mbps)

Interface: 75 Ohm BNC



● Environmental Indicators

Operating Temperature: -10°C to +60°C

Storage Temperature: -40°C to +85°C

Operating Humidity: 0% to 95% (non-condensing)

MTBF: >100,000 hours

Specifications

Product Model FCVH-V16b
Function Description Simultaneously transmits 16 channels of 12Gbps HD-SDI signals over optical fiber
Port Description 1 optical fiber port; 16 ports 12Gbps HD-SDI
Power Supply AC220V / DC-48V / DC+24V (Optional power supply)
Product Dimensions (L×W×H) 485*200*45mm, 1U rack-mounted
Weight 1.65Kg per unit

Application

application of 16-Port 12G-SDI to Fiber Converter
