This product provides 1~4channel FXO/FXS/2/4 wire audio, Magnet telephone Interface, 2* Fast Ethernet interface, and it supports VLAN division. It has a sound alarm function, it’s stable and reliable, and it has low power consumption, high integration, and small size.
- Product Search Guide: space = AND, | = OR, ! = NOT
4Voice+2FE Fiber Mux
Model
FCP-O4F2/FCP-S4F2
Description :
This product provides 1~4 channels FXO/FXS/2/4 wire audio, magnet telephone Interface; 2 Fast Ethernet interface, and it supports VLAN division.
Overview
Features
● Based on self-copyright IC;
● 4-channel voice access, support caller ID function and reverse polarity billing functions;
● 2-channel Ethernet interface, the rate of 10/100M, full/half duplex adaptive, 2x Ethernet can be set to logical isolation;
● Support FXO/FXS, EM2/4 audio, Magnet Telephone Interface, FXO port docking with program-controlled switchboard, FXS port connected to the user’s telephone;
● Support Telephone Number mutual function of each site;
● optical port unrepeated transmission distance of up to 2 to 120 km;
● Telephone interface with lightning protection, lightning reached IEC61000-4-5 Short circuit current wave 8/20μs,the peak output voltage 6KV open standards.
● Multiple power mode options: AC220V, DC-48V/DC24V, etc.
Parameters
● Fiber
Multi-mode Fiber
50/125um, 62.5/125um,
Maximum transmission distance: 5Km @ 62.5/125um single mode fiber, attenuation (3dbm/km)
Wave Length: 820nm
Transmitting power: -12dBm (Min) ~-9dBm (Max)
Receiver sensitivity: -28dBm (Min)
Link budget: 16dBm
Single-mode Fiber
8/125um, 9/125um
Maximum transmission distance: 40Km
Transmission distance: 40Km @ 9 / 125um single mode fiber, attenuation (0.35dbm/km)
Wave Length: 1310nm
Transmitting power: -9dBm (Min) ~-8dBm (Max)
Receiver sensitivity: -27dBm (Min)
Link budget: 18dBm
● Ethernet Interface (10/100M)
Interface rate: 10/100 Mbps, half/full duplex auto-negotiation
Interface Standard: Compatible with IEEE 802.3, IEEE 802.1Q (VLAN)
MAC Address Table Capacity: 4096
Connector: RJ45, support Auto-MDIX
● FXS Phone Interface
Ring voltage: 75V
Ring frequency: 25HZ
2-line Impedance: 600 Ohm (pick up)
Return loss: 40 dB
● FXO Switch Interface
Ring detect voltage: 35V
Ring detection frequency: 17HZ-60HZ
2-line Impedance: 600 Ohm (pick up)
Return loss: 40 dB
● EM 2/4 Line
AD: 0dB
DA: -3.5dB
2/4-line Impedance: 600 Ohm
Return loss: 20 dB
● Working Environment
Working temperature: -10°C ~ 50°C
Working Humidity: 5%~95 % (no condensation)
Storage temperature: -40°C ~ 80°C
Storage Humidity: 5%~95 % (no condensation)
Specifications
| Model | FCP-O4F2/FCP-S4F2 |
| Function Description | 4*POTS (FXO/FXS/2 wire Voice) +2*FE Ethernet Over Fiber, Desktop Type, 1 Fiber interface |
| Power |
Power supply: AC180V ~ 260V; DC –48V; DC +24V Power consumption: ≤10W |
| Dimension | Product Size: 216X140X31mm |
| Weight |
1.5 KG |
