The device is an Ethernet IEEE802.3 media converter, which can convert or extend the transmission distance between 10/100base-T twisted pair and 100base-FX fiber optic media. It is mainly used for long-distance (20/40/60/80/120km) transmission in fiber optic networks, and fully supports transmission rates of 10/100Mbps.
- Product Search Guide: space = AND, | = OR, ! = NOT
Fast Ethernet Fiber Media Converter
Model
FCM-FCM-F1
Description :
The device is an Ethernet IEEE802.3 media converter, which can convert or extend the transmission distance between 10/100base-T twisted pair and 100base-FX fiber optic media.
Overview
Features
● The device automatically adapts to 10/100Mbps environments, making it easy to upgrade with different networks.
● It is equipped with crash monitoring and self-reset functions, making it capable of working in high-traffic video transmission environments for extended periods without crashing, greatly reducing the workload for equipment maintenance.
● It has a built-in large-capacity, high-speed rate buffer, and a backplane switching bandwidth of 1.4G, which can prevent the transmission picture from stuttering due to frame bursting caused by rapid changes in monitoring images, such as car lights reflecting on rainy nights.
● It supports the transmission of VLAN oversized packets, supporting Ethernet packets of up to 1552 bytes, making it suitable for some jumbo frame network image transmission protocols.
● It supports full-duplex and half-duplex network communication, with automatic negotiation capabilities, and the ethernet port MDI/MDI-X is self-adaptive and does not require manual adjustment, making it convenient for on-site cable installation.
● It supports the IEEE 802.3az energy-saving protocol, with low power consumption and low heat generation, making it capable of stable operation for extended periods.
● The Ethernet interface has three-level lightning protection, with lightning protection up to GB/T17626.5(IEC61000-4-5) short-circuit current wave 8/20μs, and open-circuit peak output voltage of 6KV standard.
● The external AC220/5V power adapter can also be configured with DC-48V/5V power adapter.
● It has multiple power supply options, such as AC220V, DC-48V/DC24V, and supports AC+DC dual power backup mode.
Parameters
● Ethernet UTP Port
Rate: 10/100M, half/full duplex auto-negotiation
Standard: Compatible with IEEE 802.3, IEEE 802.1Q (VLAN)
MAC Address Table: 4096
Connector: RJ45, support Auto-MDIX
● Fiber Port
Fiber type: Single/Dual Fiber
Fiber interface: FC/SC/ST/LC (SFP)
Wavelength: 850nm/1310nm for multi-mode, 1310nm/1550nm for single-mode
Relay-free Transmission distance: 20~120Km
Typical transmission power:
Single-mode 1310/1550nm: ≥-9dBm
Multi-mode 850nm: -18dBm
Multi-mode 1310nm: -25dBm
Receiving sensitivity range: -28dBm~-40dBm
● Working Environment
Working temperature: -10°C ~ 50°C
Working Humidity: 5%~95 % (no condensation)
Storage temperature: -40°C ~ 80°C
Storage Humidity: 5%~95 % (no condensation)
Specification
| Model |
FCM-FCM-F1 |
| Function Description | 1*FE+1*100Base-S/LX media converter (Mini Tpye), Built AC220 or DC48V power supply |
| Port Description |
1 optical port, 1 FE port |
|
Power Supply |
Power supply: AC180V ~ 260V; DC –48V; DC +24V Power consumption: ≤10W |
|
Dimension |
140 X110 X30mm |
|
Weight |
0.5kg/set |
Application
Related Products
Documentation and project verification — FCM-FCM-F1
Before ordering or wiring, confirm the exact model and configuration, interface pinout, optical or network compatibility, power input and installation conditions. Optional configurations are not interchangeable.
Browse FCTEL technical documents · Request the current model-specific datasheet and wiring diagram
