Mini Industrial Rail Type 8 Ports FE Fiber Optical Media Converter

View : 110
Type : Industrial Fiber Media Converter
Description :

This series of products is an industrial grade 8 port 10/100Base-T to 100Base-FX fiber conversion, mainly used for fiber network long distance (20/40/60/80/120 km) transmission.


This series of products is an industrial grade 8 port 10/100Base-T to 100Base-FX fiber conversion, mainly used for fiber network long-distance (20/40/60/80/120 km) transmission. This product provides 1 channel 100 megabits optical port; 100 Mbit/s Ethernet electrical ports share 100 Mbit/s bandwidth. It has the perfect alarm function, stable and reliable operation, low power consumption, high integration, and small size.


Industrial Rail Type 8 Ports 10/100M Fiber Media Converter


IP40 shell protection grade can withstand the test of harsh environments;

The device provides eight 100 Mbit/s Ethernet electrical ports and one 100 Mbit/s optical port, sharing 100 Mbit/s bandwidth. The transmission bandwidth is 100 Mbit/s line speed. The optical port supports transmission of 20km, 40km, 60km, 80km, and 120km,

Support VLAN long packet transmission, can with the support of IEEE802.1Q protocol switch products matching use;

Electric interface (RJ45 interface) supports 10/100 M adaptive, full/half duplex mode, MDI/MDI – X automatic detection,

Has broadcast storm protection, balance the traffic conflict, isolation, detection of error and crash since the reset function, suitable for big traffic data applications such as video transmission;

Power to support strong lightning protection function: lightning protection, induction of high pressure resistance, anti-surge, etc.; Efficient heat dissipation without a fan, reducing repair time;

Double DC power supply terminals (5.08) :

can DC9 or AC7-50 to 55v wide range power supply, power supply has polarity automatic detection function, you do not need to distinguish between when installation is negative;

support internal isolation, redundant double power input; Anti-reverse connection protection.

When the AC power supply (three clubs AC) :

support AC – 85-265 – v AC, 300 v dc, or DC110 wide range input.

DIN 35mm rail mounting, or wall-mounted mounting;

Wide temperature type: working temperature 40 ℃ ~ + 85 ℃;

All models by 100% baking machine test, warranty period: 5 years;


● Fiber Port

Fiber Port: 1

Optical fiber: single-fiber, dual-fiber

Optical fiber port: FC/SC/ST Optional

Wavelength: 850nm/1310nm multi-mode; 1310 nm / 1550 nm single mode

Transmission distance without trunk: 20~120Km

Typical transmitted power:

Single mode 1310/1550nm: ≥-9dBm

Multi-mode 850nm: -18dBm

Multimode 1310 nm: 25 dBm

Acceptable sensitivity range: -28dBm~ -40dBm


● 10/100M Ethernet interface

Protocol: comply with IEEE 802.3a, IEEE 802.3z

Rate: 10/100M adaptive, full duplex/half duplex adaptive

MAC address table: 4096 MAC addresses

Physical interface: RJ45, support Auto-MDIX


● Environmental indicators

Operating temperature: -40 ℃ – +85 ℃

Storage temperature: -40 ℃ – +85 ℃

Humidity: 0% -95% (non-condensing)

MTBF:> 100,000 hours


Product model


Product Function Description

Transmit 8 channels of 100 Mbit Ethernet simultaneously over optical fibers

Service port description

1 optical fiber port; 8-channel 100 Mbit/s Ethernet


Power supply

DC power supply:

Redundant dual power input DC9-70V or AC7-50V, power consumption <5W

Overload protection: supported; Backconnect protection: support; Redundancy protection: Supported

Access terminal: 4-core 5.08mm pitch insert terminal

AC built-in power supply:

AC~85-265V AC, or DC110-300V DC wide input, power consumption <5W

Overload protection: supported;

Access interface: three plum AC seats

Product Size

Size: 110mm(length) x 86mm(width)x 50mm(height)

Installing method: railed installation, wall-mounted installation


0.495Kg / PCS


application of 8 port fiber media converter
